HPE ProLiant DL385 Gen10 Plus v2 8LFF Configure-to-order Server P38409-B21 P38410-B21 P38411-B21 P38412-B21 CTO 2u rack

Place of Origin:	Beijing, China
Brand Name:	HPE
Model Number:	P38409-B21

Minimum Order Quantity:	2 pieces
Price:	$3,500.00/pieces >=2 pieces
Packaging Details:	New Original Packing
Supply Ability:	100 Piece/Pieces per Year

Private Mold:	NO	Products Status:	Stock
Type:	Rack	Processor Main Frequency:	2.3GHZ
Processor Type:	5218	Port:	Beijing

HPE ProLiant DL385 Gen10 Plus v2 8LFF Configure-to-order Server P38409-B21 P38410-B21 P38411-B21 P38412-B21 CTO 2u rack 2

HPE ProLiant DL385 Gen10 Plus v2 8LFF Configure-to-order Server P38409-B21 P38410-B21 P38411-B21 P38412-B21 CTO 2u rack 3

HPE ProLiant DL385 Gen10 Plus v2 8LFF Configure-to-order Server P38409-B21 P38410-B21 P38411-B21 P38412-B21 CTO 2u rack 4

Product Description

Factory Integrated Models (CTO) - Configured Components are integrated at the factory

1 ProLiant DL385 Gen10 Plus v2 8LFF Configure-to-order Server (P38409-B21)CTO

Processor: AMD EPYC 7413 for Gen10 Plus Servers

Memory: HPE 32GB (1x32GB) Dual Rank x4 DDR4-3200 CAS-22-22-22 Registered Smart Memory Kit

Controller: Broadcom MegaRAID MR416i-a x16 Lanes 4GB Cache NVMe/SAS 12G Controller

Networking:: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter

Power Supply: HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

2 ProLiant DL385 Gen10 Plus v2 12LFF Configure-to-order Server (P38410-B21)CTO

Processor: AMD EPYC 7543 for Gen10 Plus Servers

Memory: HPE 32GB (1x32GB) Dual Rank x4 DDR4-3200 CAS-22-22-22 Registered Smart Memory Kit

Controller: Broadcom MegaRAID MR416i-a x16 Lanes 4GB Cache NVMe/SAS 12G Controller

Networking: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter

Power Supply: HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

3 ProLiant DL385 Gen10 Plus v2 8SFF Configure-to-order Server (P38411-B21)CTO

Processor: AMD EPYC 7313 for Gen10 Plus Servers

Memory: HPE 32GB (1x32GB) Dual Rank x4 DDR4-3200 CAS-22-22-22 Registered Smart Memory Kit

Controller: Broadcom MegaRAID MR216i-a x16 Lanes without Cache NVMe/SAS 12G Controller

Networking: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter

Power Supply: HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

4 ProLiant DL385 Gen10 Plus v2 24SFF Configure-to-order Server (P38412-B21)CTO

Processor: AMD EPYC 7713 for Gen10 Plus Servers

Memory: HPE 32GB (1x32GB) Dual Rank x4 DDR4-3200 CAS-22-22-22 Registered Smart Memory Kit

Controller: Broadcom MegaRAID MR216i-a x16 Lanes without Cache NVMe/SAS 12G Controller

Networking: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter

Power Supply: HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

Specification

H PE ProLiant DL385 Gen10 Plus v2 server

Form Factor

· 2U rack

Chassis Types

· 8 SFF with optional Universal Media Bay, and optional SFF or NVMe drive bay options

· 24 SFF bay with 8 SFF mid tray drives and 4 SFF rear drive bay option to total 36 SFF drives

· 8 LFF with Universal Media Bay, and optional SFF or NVMe drive bay options

· 12 LFF with optional 4 LFF mid tray and optional 4 LFF to total 20 LFF drives

Notes:

- DL385 Gen10 Plus v2 uses Basic Carrier drive cages, not Smart Carrier drive cages as used on DL385 Gen10 Plus.

- The 4 LFF rear drive box will consume space for the primary and secondary riser.

- The 8 and 12 LFF chassis also supports the 2 SFF rear drive box which allows for the user to attach a secondary or tertiary
riser.

- The 24 SFF chassis already supports 3x 8 SFF SAS/SATA drive cage kits

- The 8 NVMe U.3 or U.2 cage kits (P27194-B21, P26931-B21, P26932-B21) can only be leveraged in the SFF chassis and replaces Box
1, 2 or 3.

- The Universal Media Bay (P14609-B21) not available with the LFF chassis or the 24 SFF front, and can only be populated in Box 1.

- The 8 NVMe SFF can be upgraded with additional two front 8 NVMe SFF U.3 or U.2 drive boxes (P27194-B21, P26931-B21, P26932-B21)
to total 24 SFF NVMe drives, and up to 32 SFF NVMe drives with one mid 8 NVMe SFF mid-tray drive cage (P39600-B21, P38847-B21).
U.3 and U.2 front and mid drive cages cannot mix.

- U.3 x1 and x4 drive cages cannot mix.

- The 8 LFF chassis cannot be upgraded to 12 LFF front in the field.

- 12 LFF or more drives require Max performance fan kit (P14608-B21).

- CPU selection is limited 225W (Turbo to 240W) or lower with 4LFF mid-tray selected & DIMM blanks populate empty DIMM slots.

System Fans

Standard – fan types included

· The 8 SFF chassis ship with 4 standard fans as standard.

· The 8 LFF chassis ships with 6 standard fans as standard.

· The 12 LFF and 24 SFF chassis ship with 6 max performance fans as standard.

· Max performance fan kit is available to meet ambient temperature environments.

· Max performance fan kits are required for rear drives, or >155w Processors SKUs, or if High Performance NVMe/SAS4 drives being
used.
