PowerEdge MX7000 | ||
Features | Technical Specification | |
Processor | Up to 6 3000W; PSU and grid redundancy support | |
Fans | 5 rear- and 4 front-accessible hot-swap fans | |
Dimensions (LxWxD) | 816.8mm (32. 16 inches) x 482mm (18.98 inches) x 307.4mm (12. 10 inches) | |
Rack Units | 7U | |
Embedded mgmt | MX7000 chassis: OpenManage Enterprise Modular Edition (OME-Modular); running on up to 2 redundant MX9002m management modules Unified control: single management point for server, storage and networking Intelligent automation: Operational template methodology and comprehensive RESTful API Quick Sync 2 Bluetooth Low Energy (BLE)/wireless module option On compute sled: As every other PowerEdge server, the integrated Dell Remote Access Controller (iDRAC)9 with Lifecycle Controller (LC) | |
Bezel | ||
OpenManage™ SW | OpenManage Enterprise OpenManage Essentials OpenManage Mobile (OMM) OpenManage Power Center (OMPC) | |
Integrations & Connections | Integrations: Microsoft® System Center VMware® vCenter™ BMC Software (available from BMC) Ansible by Red Hat | Connections: Nagios Core and Nagios XI Oracle Enterprise Manager Microfocus Operations Manager (OM) and Operations Manager i (OMi) IBM Tivoli Netcool/OMNIbus |
Security | TPM 1.2/2.0 (optional) Cryptographically signed firmware Silicon Root of Trust | Secure Boot System Lockdown (requires OpenManage Enterprise) System Erase |
Embedded NIC | ||
Networking Options (NDC) | Fabric options: Up to 2 pairs of redundant general-purpose switch or pass-through modular bays (Fabrics A and B); redundant pair of storage specific switch bays (Fabric C) Up to 25GbE, 32Gbps Fibre Channel, 12Gbps SAS | |
GPU Options | ||
Front Ports | 2 USB 2.0 Type A or KVM control (keyboard and mouse only) 1 USB 2.0 Type Micro-AB direct management port 1 Mini Display Port connector for video Front buttons/indicators: Power button | System status LED Health icon Ambient temperature icon IOM icon Fan icon Stack/group icon ID button |
Recommended support | Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visit Dell.com/itlifecycleservices. | |
Dell Financial Services | Deliver results with easy financing. Explore financial options that move at the speed of business. For more information, visit Dellemc.com/global-financial-services. | |
PowerEdge Architecture | PowerEdge MX | PowerEdge FX2/PowerEdge FX2S | PowerEdge VRTX |
Form factor | 7U enclosure with 8 slots | Full-width, 2U enclosure | Tower or 5U rack modular chassis |
Description | Modular chassis that accommodates a variety of compute and storage sled combinations, connected by high-speed fabrics, sharing power, cooling and managed by embedded OpenManage Enterprise – Modular Edition systems management | An industry standard 2U rack-mount chassis that supports shared, redundant power and cooling, I/O fabric and management infrastructure and accommodates compact, customizable blocks of server storage and networking. | Integrates servers, storage, networking and management into a quiet data center under your desk |
I/O slots | 2 USB 2.0 Type A or KVM control (keyboard and mouse only) 1 Mini Display Port connector for video | FX2s: Supports up to 8 low-profile/half-length PCIe 3.0 modules | Up to 8 PCIe slots |
Server Sleds | Up to 8 PowerEdge MX740c Up to 4 PowerEdge MX840c | Up to 8 FC430 Up to 4 FC640 Up to 2 FC830 Up to 1 FC830 mixed with up to 2 FC640 | Up to 4 M640 Up to 2 M830 |
Storage Sleds | Up to 7 PowerEdge MX5016s | FX2S: Up to 2 FD332 mapped to 4 FC430 Up to 3 FD332 mapped to 1 FC640 Up to 2 FD332 mapped to 2 FC640 Up to 2 FD332 mapped to 1 FC830 | Internal: Up to 12 x 3.5” or 25 x 2.5” drives (SED available) External: Up to four MD1200 (12 x 3.5” drives) or MD1220 (24 x 2.5” drives) |
Power Supplies | Up to 6 PSUs; Platinum rated – 3000W output with high line AC input; N+1 or Grid redundancy support | Hot-plug PSUs: Platinum rated – 2400 W, 2000 W, or 1600WAC in 1+1 redundant or ROA or 2+0 non-redundant configurations | Supports up to four 1100 W or 1600 W AC power supply units (PSU) in 3+1 and 2+2 redundant configurations |
Fans | 5 80 mm rear and 4 60mm front hot-swap fans | 8 hot-swappable fans provide cooling to the I/O components in the system | 6 hot-pluggable, redundant fan modules and 4 blower modules |
I/O and Ports | Up to 2 pairs of redundant general-purpose switch or pass-through modular bays (Fabrics A and B); redundant pair of storage specific switch bays (Fabric C) Up to 25Gbps Ethernet, 32Gbps Fibre Channel, 12Gbps SAS | Choice of 3 Dell EMC modules: FN410s 4-ports SFP+, FN410t 4-port 10Gb Base-T, FN2210s 4-port Combination of 2 Fibre Channel and 2 Ethernet ports, or 2 pass-through modules. | Internal 1GbE 24-port switch Internal 10GbE switch Internal 1GbE 8-port pass-through module |
Embedded Management | OpenManage Enterprise – Modular Edition (OME-Modular); running on up to 2 redundant MX9002m management modules Quick Sync 2 Bluetooth Low Energy (BLE)/ wireless module option | One Chassis Management Controller (CMC) | Chassis Management Controller (CMC) |
